Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
2-242 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Explanation of the formal parameters
The table below shows all formal parameters of the "MCP_IFT" function:
Signal I/O Type Value range Remarks
BAGNo I Byte 0 - b#16#0A
and
b#16#10 - b#16#1A
No. of mode group to which the
mode signals are transferred.
ModeGroupNo >= b#16#10 means
access to the second machine
control panel.
ChanNo I Byte 0 - B#16#0A Channel no. for the channel signals
SpindleIFNo I Byte 0 - 31
(B#16#1F)
Number of the axis interface
declared as a spindle
FeedHold Q Bool Feed stop from machine control
panel, modal
SpindleHold Q Bool Spindle stop from machine control
panel, modal
Call example
CALL FC 25 ( //Machine control panel T variants
//signals to interface
BAGNo := B#16#1, //Mode group no. 1
ChanNo := B#16#1, //Channel no. 1
SpindleIFNo := B#16#4, //Spindle interface
//number = 4
FeedHold := m22.0, //Feed stop signal
//modal
SpindleHold := db2.dbx151.0); //Spindle stop modal in
//message DB
With these parameter settings, the signals are sent to the 1st mode group, the 1st channel
and all axes. In addition, the spindle override is transferred to the 4th axis/spindle interface.
The feed hold signal is passed to bit memory 22.0 and the spindle stop signal to data block
DB2, data bit 151.0.
