Siemens SINUMERIK 810D Programming Guide

15
Tables 04.00
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
15-518
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_DP23
REAL $TC_DP23[t,d]
Base – Length 3
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP23[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP24
REAL $TC_DP24[t,d]
Clearance angle
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP24[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP25
REAL $TC_DP25[t,d]
Reserved
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP25[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 4
$TC_DPCE
INT $TC_DPCE[t,d] = 'Cutting edge number' of offset data block t,d
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DPCE[d]
CE stands for <C>utting<E>dge
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_DPH
INT $TC_DPH[t,d] = 'H cutting edge number' of offset data block t,d for
Fanuc0 M
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DPH[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
.
