Siemens Sinumerik 840 sl Function Manual

Detailed description
2.4 Frames
Basic logic functions: Axes, coordinate systems, frames (K2)
132 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
MD20110
Significance
Bit 0 = 1 and bit 14 = 0 Chained complete basic frame is deleted.
The complete basic frame is derived on the basis of:
MD24002 $MC_CHBFRAME_RESET_MASK
(active channel-specific basic frame after RESET)
and
MD10613 $MN_NCBFRAME_RESET_MASK
(active NCU global basic frame after RESET)
MD24002 $MC_CHBFRAME_RESET_MASK
Bit 0 = 1 1. 8th channel basic frame is calculated into the chained
complete basic frame.
Bit 7 = 1 8. 8th channel basic frame is calculated into the chained
complete basic frame.
MD10613 $MN_NCBFRAME_RESET_MASK
Bit 0 = 1 1. 8th NCU global basic frame is calculated into the
chained complete basic frame.
Bit 0 = 1 and bit 14 = 1
Bit 7 = 1 8. 8th NCU global basic frame is calculated into the
chained complete basic frame.
Frame conditions after RESET / parts program end
Frame condition after RESET / part program end
Programmable frame Deleted.
Settable frames Retained, depending on
MD20110 $MC_RESET_MODE_MASK
and
MD20152 $MC_GCODE_RESET_MODE.
Complete basic frame Retained, depending on:
MD20110 $MC_RESET_MODE_MASK Bit 0 and Bit 14,
MD10613 $MN_NCBFRAME_RESET_MASK
and
MD24002 $MC_CHBFRAME_RESET_MASK.
System frames Retained, depending on
MD24006 $MC_CHSFRAME_RESET_MASK
and
MD20150 $MC_GCODE_RESET_VALUES[ ].
External zero offset Retained
DRF offset Retained
