1.3.6 ShopTurn Open (PCU 50.3)
There is ShopTurn software for the PCU 50.3 in the ShopTurn Open
version.
In ShopTurn Open, the HMI-Advanced operator sections "Services",
"Diagnosis", "Commissioning" and "Parameters" (without tool
management and zero-point offsets) are located directly on the
expanded horizontal softkey bar.
You can find a detailed description of the integrated HMI-Advanced
operator interface in:
References: /BAD/, Operator's Guide HMI Advanced
SINUMERIK 840D/840Di/810D/840D sl
Some of the softkeys in the basic menu or extended menu bars may
be assigned to other operating areas by the machine manufacturer.
Please also refer to the machine manufacturer's instructions.

