A.8 Information List
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
740
7211 Backup O/C General TRIP
command (O/C TRIP)
Back-Up O/C OUT * * * LED BO 64 111 2 No
7212 Backup O/C TRIP - Only L1 (O/C
TRIP 1p.L1)
Back-Up O/C OUT * on * LED BO 64 112 2 No
7213 Backup O/C TRIP - Only L2 (O/C
TRIP 1p.L2)
Back-Up O/C OUT * on * LED BO 64 113 2 No
7214 Backup O/C TRIP - Only L3 (O/C
TRIP 1p.L3)
Back-Up O/C OUT * on * LED BO 64 114 2 No
7215 Backup O/C TRIP Phases L123
(O/C TRIP L123)
Back-Up O/C OUT * on * LED BO 64 115 2 No
7221 Backup O/C TRIP I>> (O/C TRIP
I>>)
Back-Up O/C OUT * on * LED BO 64 121 2 No
7222 Backup O/C TRIP I> (O/C TRIP
I>)
Back-Up O/C OUT * on * LED BO 64 122 2 No
7223 Backup O/C TRIP Ip (O/C TRIP
Ip)
Back-Up O/C OUT * on * LED BO 64 123 2 No
7235 O/C I-STUB TRIP (I-STUB TRIP) Back-Up O/C OUT * on * LED BO 64 135 2 No
7325 CB1-TEST TRIP command -
Only L1 (CB1-TESTtrip L1)
Testing OUT on
off
* * LED BO 153 25 1 Yes
7326 CB1-TEST TRIP command -
Only L2 (CB1-TESTtrip L2)
Testing OUT on
off
* * LED BO 153 26 1 Yes
7327 CB1-TEST TRIP command -
Only L3 (CB1-TESTtrip L3)
Testing OUT on
off
* * LED BO 153 27 1 Yes
7328 CB1-TEST TRIP command L123
(CB1-TESTtrip123)
Testing OUT on
off
* * LED BO 153 28 1 Yes
7329 CB1-TEST CLOSE command
(CB1-TEST close)
Testing OUT on
off
* * LED BO 153 29 1 Yes
7345 CB-TEST is in progress (CB-
TEST running)
Testing OUT on
off
* * LED BO 153 45 1 Yes
7346 CB-TEST canceled due to Power
Sys. Fault (CB-TSTstop FLT.)
Testing OUT_
Ev
on *
7347 CB-TEST canceled due to CB
already OPEN (CB-TSTstop
OPEN)
Testing OUT_
Ev
on *
7348 CB-TEST canceled due to CB
was NOT READY (CB-TSTstop
NOTr)
Testing OUT_
Ev
on *
7349 CB-TEST canceled due to CB
stayed CLOSED (CB-TSTstop
CLOS)
Testing OUT_
Ev
on *
7350 CB-TEST was successful (CB-
TST .OK.)
Testing OUT_
Ev
on *
10201 >BLOCK Uph-e>(>) Overvolt.
(phase-earth) (>Uph-e>(>) BLK)
Voltage Prot. SP * * * LED BI BO
10202 >BLOCK Uph-ph>(>) Overvolt
(phase-phase) (>Uph-ph>(>)
BLK)
Voltage Prot. SP * * * LED BI BO
10203 >BLOCK 3U0>(>) Overvolt. (zero
sequence) (>3U0>(>) BLK)
Voltage Prot. SP * * * LED BI BO
10204 >BLOCK U1>(>) Overvolt. (posi-
tive seq.) (>U1>(>) BLK)
Voltage Prot. SP * * * LED BI BO
10205 >BLOCK U2>(>) Overvolt. (nega-
tive seq.) (>U2>(>) BLK)
Voltage Prot. SP * * * LED BI BO
10206 >BLOCK Uph-e<(<) Undervolt
(phase-earth) (>Uph-e<(<) BLK)
Voltage Prot. SP * * * LED BI BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
