Siemens SIRIUS 3RW44 - Page 187

PROFIBUS DP Communication Module
SIRIUS 3RW44 manual
GWA 4NEB 535 2195-02 DS 06
8-63
12 24
7
Temperature sensor monitoring x • No [0]
•Yes [1]
25 -26 Reserved = 0
15 28 Minimum current limit value 18.75 ... 100 % [6 ... 32] 3.125 %
16 29 Maximum current limit value 50 ... 150 % [16 ... 48] 3.125 %
30 - 31 Reserved = 0
32
0-5
Reserved = 0
14 32
6
Response to current limit value violation x • Warning [0]
•Tripping [1]
32
7
Reserved = 0
33
0-1
Reserved = 0
140 33
2
Response to overload - contact block x • Tripping without
restart [0]
• Tripping with restart [1]
33
4-7
Reserved = 0
21 34
0-2
Asymmetric limit value x 30 ... 60 % [3 ... 6] 10 %
34
3-5
Reserved = 0
20 34
6
Response to asymmetry x • Warning [0]
•Tripping [1]
22 34
7
Response to ground fault x • Warning [0]
•Tripping [1]
35 - 44 Reserved = 0
47 45 Braking torque 20 ... 100 % [4 ... 20] 5 %
46 - 47 Reserved = 0
40 48 Start voltage 20 ... 100 % [4 ... 20] 5 %
49 Reserved = 0
42 50 Current limiting value • 3RW44 2, 3, 4:
125 ... 550 % [40 ... 176]
•3RW445:
125 ... 500 % [40 ... 160]
•3RW446:
125 ... 450 % [40 ... 144]
3.125 %
167 51
0-3
Starting mode • Direct on line [0]
• Voltage ramp [1]
• Torque control [2]
• Motor heating [3]
• Voltage ramp + current limiting
[5]
• Torque control + current limiting
[6]
ID
No.
Byte
Bit
Meaning
Only for
data set
131
Value range [coding] Factor
