Basic information about the drive system
13.12 System rules, sampling times and DRIVE-CLiQ wiring
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
1021
Changing the offline topology in the STARTER commissioning tool
The device topology can be changed in the STARTER commissioning tool by shifting the
components in the topology tree.
Example: Changing the DRIVE-CLiQ topology
1. Select the DRIVE-CLiQ component.
2. While holding down the mouse button, drag the component to the required DRIVE-CLiQ
interface and release the mouse button.
You have changed the topology in the STARTER commissioning tool.
