Siemens SIROTEC Function Manual

Basic information about the drive system
13.12 System rules, sampling times and DRIVE-CLiQ wiring
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
1031
Using EPOS
The following table lists the number of axes that can be operated with a SINAMICS S120
when using a "basic positioner" (EPOS) function module. The number of axes depends on
the current controller sampling time.
Table 13- 21 Sampling times when using EPOS
Cycle times [µs]
Cycle times [ms]
Number
Current controller
Speed controller
Position controller
Positioner
Axes
Infeed
250
250
2
8
6
1 [250 μs]
250
250
1
4
5
1 [250 μs]
125 125 1 4 4 1 [250 μs]
The CPU processing time required for the function module EPOS (with 1 ms position
controller/4 ms positioner) corresponds to the same CPU processing time of 0.5 V/f axes
with 500 μs.
Use of the SINAMICS Web server
The available computation time can be used for the SINAMICS Web server. The following
boundary condition applies here:
● The utilization of the system (r9976) must be less than 90%!
● A maximum of five users can access data on the same drive via the SINAMICS Web
server.
Using CUA31/CUA32
Information on using the Control Unit Adapter CUA31 or CUA32:
● CUA31/32 is the first component in the CUA31/32 topology: 5 axes
● CUA31/32 is
not
the first component in the CUA31/32 topology: 6 axes
● For a current controller sampling time of 62.5 µs, only one axis is possible with one
CUA31/32.
13.12.5.2
Cycle mix for servo control and vector control
Supplementary conditions
The rules for setting the sampling time (see Section Rules when setting the sampling times
(Page 1007)) and the rules on isochronous mode (see Section Rules for isochronous mode
(Page 1009)) apply.
These rules mean that the smallest common multiple of the current controller sampling times
of all axes operated on the isochronous PROFIBUS and 125 µs is used to set T
i
, T
o
and T
dp
.
