Load gear position tracking
Position tracking enables the load position to be reproduced when using gearboxes. It can
also be used to extend the position area.
Position tracking for load gear, functions in the same way as position tracking for the
measuring gear (see "Measuring gear position tracking"). Position tracking is activated via
parameter p2720.0 = 1. The position tracking of the load gear, however, is only relevant for
the motor encoder (encoder 1). The load gear ratio is entered via parameters p2504 and
p2505. Position tracking can be activated with rotary axes (modulo) and linear axes.
Position tracking for the load gear can only be activated once for each motor data set MDS.
The load actual position value in r2723 (must be requested via Gn_STW.13, see Section
"Control and status words for encoders") comprises the following information:
● Encoder pulses per revolution (p0408)
● Fine resolution per revolution (p0419)
● Virtual number of stored revolutions of a rotary absolute encoder (p2721)
● Load gear ratio (p2504/p2505)
● Measuring gear ratio (p0433/p0432), if p0411.0 = 1
Note
The sum of p0408, p0419 and p2721 is limited to 32 bits.
Note
Load gear problems and solutions, see example in
Section Position tracking -> Measuring
● Absolute encoder
● Configuration via p2720
● Virtual multiturn via p2721
● Tolerance window for monitoring the position at switching on p2722
● Input of the load gear via p2504 and p2505
● Display via r2723
