Siemens SIROTEC Function Manual

Communication
11.3 Communication via PROFINET IO
Drive functions
826 Function Manual, 11/2017, 6SL3097-4AB00-0BP5
11.3.5
Communication with CBE20
The CBE20 is a Communication Board that can be flexibly used and which can be operated
with different communication profiles. Only one firmware of a communication profile can be
loaded at any one time. The available firmware files are saved with the communication
profiles in UFW files on the Control Unit memory card. Firmware can only be selected prior
to commissioning.
The required file is selected using parameter p8835. A POWER ON must be carried out after
selecting the desired UFW file. During the subsequent system boot, the corresponding UFW
file is loaded. The new selection then becomes active.
Table 11- 16 Functionality and selection in the pointer file
Functionality (p8835)
Content
Detailed information on this:
PROFINET device
1
-
PROFINET Gate 2 Section "Communication via PROFINET Gate
(Page 827)"
SINAMICS Link 3 Section "Communication via SINAMICS Link
(Page 888)"
EtherNet/IP 4 Section "Communication via EtherNet/IP
(Page 873)"
Modbus TCP 5 Section "Communication via MODBUS TCP
(Page 857)"
Customer-specific
1)
from OEM directory
99 -
1)
Path for the UFW file and folders on the memory card: /OEM/SINAMICS/CODE/CB/CBE20.UFW
Identification of the firmware version
Using parameter r8858, the loaded firmware version of the PROFINET interface can be
identified uniquely.
Overview of important parameters (see SINAMICS S120/S150 List Manual)
•
p8835
CBE20 firmware selection
•
r8858[0...39]
COMM BOARD read diagnostics channel
•
r8859[0...7]
COMM BOARD identification data
