Basic information about the drive system
13.4 BICO technology: Interconnecting signals
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
955
13.4.6
Scaling
Signals for the analog outputs
Table 13- 4 List of signals for analog outputs
Signal
Parameter
Unit
Scaling
(100% = ...)
Speed setpoint before the
setpoint filter
r0060 rpm p2000
Actual speed value, motor
encoder
r0061 rpm p2000
Actual speed value
r0063
rpm
p2000
Drive output frequency
r0066
Hz
Reference frequency
Absolute actual current value
r0068
Arms
p2002
Actual DC-link voltage value
r0070
V
p2001
Total torque setpoint
r0079
Nm
p2003
Actual active power
r0082
kW
r2004
Control deviation
r0064
rpm
p2000
Modulation depth
r0074
%
Reference modulation depth
Torque-generating current
setpoint
r0077 A p2002
Torque-generating actual cur-
rent value
r0078 A p2002
Flux setpoint
r0083
%
Reference flux
Flux actual value
r0084
%
Reference flux
Speed controller
PI torque output
r1480 Nm p2003
Speed controller
I torque output
r1482 Nm p2003
Changing scaling parameters p2000 to p2007
Note
If a per unit representation is selected and the reference parameter is subsequently changed
(e.g. p2000), the per unit values of some control parameters are automatically a
dapted so
that the control behavior does not change.
