Diagnostics
5.2 Diagnostics using LEDs
Commissioning with Startdrive
Commissioning Manual, (IH3), 07/2016, 6SL3097-4AA10-0BP0
151
5.2.4.3
Terminal Module TM41
Table 5- 17 Meaning of the LEDs on the Terminal Module TM41
LED
Color
Status
Description, cause
Remedy
READY - Off The electronics power supply is missing or outside the
permissible tolerance range.
–
Green Continuous
light
The component is ready for operation. Cyclic DRIVE-CLiQ
communication is taking place.
–
Orange Continuous
light
DRIVE-CLiQ communication is being established. –
Red Continuous
light
This component has at least one fault.
Note:
The LED is activated irrespective of whether the corre-
sponding messages have been reconfigured.
Remove and
acknowledge the fault.
Green/
red
Flashing
light 0.5 Hz
Firmware is being downloaded. –
Flashing
light 2 Hz
Firmware download is complete. The system waits for
POWER ON.
Carry out a POWER
ON.
Green/
orange
or
Red/
orange
Flashing
light
Component recognition via LED is activated
1)
.
Note:
Both options depend on the LED status when component
recognition is activated.
–
Z pulses – Off The zero mark was found and the system waits for the
zero mark output.
OR
The component is switched off.
–
Red Continuous
light
The zero mark has not been released, or the zero mark
search is running.
–
Green Continuous
light
The system stops at the zero mark. –
Flashing
light
The zero mark is output at each virtual revolution. –
1)
The parameters for activating component recognition using LEDs can be taken from the following reference:
Reference: /LH1/ SINAMICS S120/S150 List Manual
