A.3 Shortcut menus and icons in Startdrive
Commissioning with Startdrive
202 Commissioning Manual, (IH3), 07/2016, 6SL3097-4AA10-0BP0
Exporting a measurement using the settings of the current view
Exports a measurement as file with file extension "*.ttrecx" or "*.csv". File extension
"*ttrec" is supported for compatibility reasons to V12 - however, it does not contain any
information about the device family.
Importing a measurement (only for higher-level measurements)
Imports a measurement from a file with file extension "*.ttrecx".
File extension "*ttrec" is supported for compatibility reasons to V12 - however, it does
not contain any information about the device family.
Selecting a measurement (only for higher-level measurements)
The drop-down list contains the imported measurements. Select the desired measure-
ment for displaying the configuration.
Curve diagram
Shortcut menu commands
The following table shows the shortcut menu commands in the curve diagram:
Exports the actual display as bitmap.
Copy graphic to clipboard
Copies the current display to the clipboard.
Center measuring cursors Positions the activated measurement cursors at a central point
Toolbar of the curve diagram
Tools are available for adapting the display using icons.
The following table shows the functions of the icons:
Undo zoom
Undoes the zoom function executed last.
If several zoom functions have been executed, they can be undone step-by-step.
Redo zoom
Redoes the last undone zoom function. If several zoom functions have been un-
done, they can be redone step-by-step.
Standard view
Uses the current view as standard for this recording. If the trace recording is dis-
played again at a later time, then the standard view is restored.
Move view
Moving the display with the left mouse key pressed.
Zoom selection
Selects an arbitrary range with the left mouse key pressed. The display is scaled to
the range selection.
