2
Generation 1 / EP 33-U 1/EP 33U 1/EP 33-U Digital/ICX-404AL
2x 4x 5x 5x
Objective Lens diameter 24mm 50mm 60mm 50mm
Field of view 25º 15º 12º 4º
Field of view, m@100m 44m 26m 21m 7m
Min. focusing distance 1m 1m 5m 1m
Eye relief 12mm 12mm 12mm 12mm
Diopter adjustment +-5 +-5 +-5 +-5
Resolution, lines per mm 36mm 36mm 36mm 34mm
Max detection range 120 180 180 140
Battery type 2xAA 2xAA 2xAA 2xAA
Battery life (with IR) 20hr 20hr 20hr 5hr
Battery life (w/out IR) 72hr 72hr 72hr 9hr
Tripod mount 1/4” 1/4” 1/4” 1/4”
Operating temp. -20...40ºC -20...40ºC -20....40ºC -10...45ºC
Dimensions 139x57x74mm 185x60x83mm 210x69x90mm 210x69x90mm
Weight 8.80z 14.1oz 19.7oz 19.7oz
SM14071 SM14073 SM14074 SM18074
