Signature S40008 User Manual

7
AdjustingtheAirFlow:
This unit is equipped with a vertical tilt function, which
can be manually adjusted to better direct the air ow.
1. To adjust the vertical tilt angle of the fan, rmly
grip the top half of the motor housing and push it
gently upwards or downwards as required. The
fan will give o a clicking noise to indicate the tilt
mechanism is working.
2. Once the fan has been tilted, it will automatically
remain at the selected angle until manually
adjusted again.
NOTE:The fan’s horizontal angle cannot be manually
adjusted. To change the horizontal angle of the fan,
activate the oscillation function as detailed above,
wait until the fan is at the desired angle, then pull the
oscillation knob up to stop the oscillation function and
lock the fan into place.
Cleaningandcare:
1. Before cleaning always switch o the appliance
and remove the plug from the electrical socket.
2. To clean the outside of the fan, wipe the exterior
with a soft, damp cloth.
3. Never use an abrasive cleaner.
4. When not in use, store the fan (preferably in its
original box) in a cool, clean and dry location.
Cleaningthefanblades:
1. Remove the front guard by unclipping the locking
clips located around the circumference of the
guard. The top lock does not unclip.
2. Use a small spanner to unscrew the nut and bolt
that holds the bottom of the front guard to the
back guard.
3. With both hands, pull the front guard downwards
and away.
4. Clean the fan blades with a soft, damp cloth.
5. Slide the front guard back into place, so it ts into
the top lock clip. Clip all the locks back into place
and screw the nut and bolt back in.
Model Identier(s): S40008 Applicable to all colour variants
Item Symbol Value Unit
Maximum fan ow rate F 13.3 m
3
/min
Fan Power input P 18.2 W
Service Value SV 0.7 (m
3
/min)/W
Standby power consumption PSB 0.0 W
Seasonal electricity consumption Q 5.8 kWh/a
Fan sound power level LWA 57.7 0 dB(A)
Maximum air velocity C 1.6 m/sec
Contact Details:
Imported by RK Wholesale LTD, Berryhill Road,
Stoke-on-Trent ST4 2NL
