7
NOTICE
1. In HDMI bypass mode, users must be aware of that the jitters
coming from HDMI sources, such as DVD players, may be much
higher than typical requirement according to SMPTE request on
HD-SDI signals. This will result in SDI output with high jitters or
even no SDI outputs!
2. Due to the high frequency bandwidth and low jitter requirement
of 3G-SDI signals, it is strongly recommended to use just one SDI
OUTPUT with one 75 ohm.
3. The features including new timings and patterns may increase
 withoutnoticeafterthermwareisupdated!Thismayaectthe
menu items, but will keep the same framework for users!
APPENDIX
•  DataIdenticationWordofAncillaryDataPacket
* Data Type 1(SMPTE-291M)
ANC Data DID SDID/DBN
352M 0x41 0x01
RP-165-EDH* 0xF4 0x00
