This system consists of an extendable
handle, two wheels, and a stand (to
be used on horizontal, at surfaces).
WARNING
WARNING
Ensure that you do NOT remove the
battery pack when the vehicle is charging
nor when it is turned on.
Failure to follow this instruction can
damage the vehicle’s electronics.
Make sure you do NOT pull the handle
out before pulling the pack out (pull the
handle out once the battery is outside the
vehicle), or put it back in with the handle
pulled out (push in before inserting).
The pack’s wheels and stand
pull in and out automatically
when you put it in and
pull it out of the vehicle,
respectively. Even so, it is the user’s
responsibility to do this slowly and make
DO NOT attempt to pull the
landing gear out with your
hands or put your hands
under the battery under any
circumstances.
sure that the wheels and stand pull out
correctly when the pack is removed,
and that it properly ts into place when
inserting it back in the vehicle. Otherwise,
you run the risk of it falling on your feet,
with the consequent personal harm.
CAUTION
CAUTION
Fig. 123 - Removable battery.
Trolley-type removal system
You must charge completely every 30 days
to maintain the warranty.
To keep your battery’s warranty, you must
completely charge it (up to 100%) at least
once per month. If you foresee that you
will not be using it for a long period of
time, it is very important that you charge
it enough that it does not go down to a
critical level. A battery that exceeds a
certain low voltage limit loses autonomy
to operate, which means it cannot be
charged and needs to be brought to ocial
technical service.
INFORMATION
cold places and during cold seasons
of the year, so that the heater heats
the cells, and they are at a suitable
temperature for the vehicle to be
used normally.
Before removing the battery, you
must consider the risks associated with
this operation.
86 Use
MU_S04 MY23_EN - USER MANUAL S04 MY23 (V002)
