Silver Fox 2246B - Operation Instructions; Standard Configuration (Rocket Switch)

7.Operation Instruction
3
1
2
4
5
1 2
3 4
2246B
Press the button, the backrest angle will automatically move
to the maximum, the cushion angle will automatically move to
the maximum, leg pad angle will automatically reduce to the
minimum, the height of the bed will automatically reach the
lowest position.
1
2
3
4
5
Operation
Description
Backrest motor button
Cushion angle motor button
The leg pad motor button
Whole bed motor button
One-key reset button
Backrest goes up (goes down) smoothly by pressing the button.
Angle of cushion increases (decreases) smoothly by pressing
the button.
Angle of leg pad increases (decreases) smoothly by pressing
the button.
The whole bed goes up (goes down )smoothly by pressing
the button.
1. Standard configuration (Rocket Switch )
