Trailering Systems 2-61
North America 7–Way Trailer Connector (cont'd)
Trailering Message Description
Trailer Detected The K68 Trailer Lighting Control Module detects a trailer has been
connected to the X88 Trailer Connector.
{JL1} Trailer Brakes Detected The K133 Trailer Brake Power Control Module detects a trailer with trailer
brakes has been connected to the X88 Trailer Connector.
Trailer Disconnected Check Connection The K68 Trailer Lighting Control Module detects a trailer has been
disconnected from the X88 Trailer Connector.
Trailer Tire Pressure High The K214 Trailer Tire Pressure Indicator Module detects one or more of
the trailer tire pressures is high.
Trailer Tire Pressure Low The K214 Trailer Tire Pressure Indicator Module detects one or more of
the trailer tire pressures is low.
Trailer Tire Sensor Fault The K214 Trailer Tire Pressure Indicator Module detects one or more of
the trailer tire pressure sensors has a fault.
Trailer Tire Temperature High The K214 Trailer Tire Pressure Indicator Module detects one or more of
the trailer tire temperatures is too high.
Export 13–Way Trailer Connector Trailer
Messages
The driver information center (P16 Instrument Cluster)
or infotainment screen (P17 Info Display Module) may
display one or more of the following messages to the
user related to trailering.
Export 13–Way Trailer Connector
Trailering Message Description
Check Trailer Left Turn Signal Lamp The K68 Trailer Lighting Control Module detects a fault on the left trailer
turn lamp control circuit
Check Trailer Right Turn Signal Lamp The K68 Trailer Lighting Control Module detects a fault on the right trailer
turn lamp control circuit
Check Trailer Rear Lamp The K68 Trailer Lighting Control Module detects a fault on one or both of
the trailer park lamp control circuit(s).
Check Trailer Reversing Lamp The K68 Trailer Lighting Control Module detects a fault on the trailer
backup lamp control circuit.
Check Trailer Brake Lamps The K68 Trailer Lighting Control Module detects a fault on the trailer stop
lamp control circuit.
Check Trailer Rear Fog Lamp The K68 Trailer Lighting Control Module detects a fault on the trailer fog
lamp control circuit.
Lane Change Alert Off Reminder to the user that lane change alerts are turned off anytime a
trailer is detected.
Rear Cross Traffic Alert Off Reminder to the user that rear cross traffic alerts are turned off anytime a
trailer is detected.
Rear Park Assist Off Reminder to the user that rear park assist is turned off anytime a trailer is
detected.
Trailer Theft Detection (With U1D/
UET Only)
Trailer theft monitori ng can be turned ON and OFF
through the vehicle Trailer App. When enabled, any
time the trailer theft deterrent system is armed, the
trailer lighting circuits are constantly monitored to
determine if a trailer is connected for trailer theft
deterrent purposes. With the key OFF, the K68 Trailer
Lamp Control Module will randomly pulse the lighting
circuits of the trailer to verify it is still connected by
monitoring the voltage drop of the circuit. Depending on
the configuration of the trailer lights, the trailer lights
may randomly flash as part of the trailer theft deterrent
function. These flashes correspond to when the
K68 Trailer Lamp Control Module pulses the lighting
circuits to ensure the trailer is still connected and is
considered normal. If the trailer is disconnected while
the trailer theft deterrent system is armed, the vehicle
will flash the exterior lights and cycle the horn to alert of
a trailer theft event. Refer to Theft Systems Descript ion
and Operation for more information on the content theft
deterrent system.
2022 - Silverado 1500 (New) Electrical Body Builder Manual
