14 GB/IE/NI
R Symbol
15
The R symbol indicates random switching is
activated. The R symbol means random. In
this mode the device will switch the con-
nected loads on and off at different intervals.
S symbol
16
Indicates the clock has been set to summer
time.
ON – AUTO – OFF
18
Indicates the operating mode of the device.
Program number
21
Indicates the program number in PROGRAM
function.
AM – PM
22
Indicates the hour mode.
