7 GB/IE/NI
Scope of delivery
Unpack the product. Remove the transport locks,
if any.
After unpacking the product, check if all parts
are complete and in good condition. Remove
all packing materials (including protective foils)
before use.
1 Motor unit (with speed buttons, grille lock nut
and lock screw)
2 Cross base (with screws)
1 Blade lock nut
1 Extension pole and lower pole (with height
adjustment lock and pole cover)
1 Front grille (with lock nut and lock screw)
1 Rear grille
1 Blade
NOTE: Various removable components are
delivered pre-assembled (see “Description of
parts”).
Description of parts
Before reading, unfold the page containing the
illustrations and familiarise yourself with all the
functions of the product.
Fig. A
[1]
Front grille
[2]
Blade lock nut
[3]
Blade
[4]
Grille lock nut
[5]
Rear grille
[6]
Motor unit
[]
Motor shaft
[7]
Oscillation control knob
[8]
Speed button panel (0, 1, 2, 3)
[9]
Lock screw
[]
Extension pole
[]
Height adjustment lock
[]
Lower pole
[]
Pole cover
[]
Cross base
[]
*Screw for cross base (M6x14mm) (x4)
[]
*Lock screw and lock nut
[]
Power cord with power plug
*
pre-assembled
Technical data
Input voltage: 220–240 V
~~
, 50–60 Hz
Power consumption: 45 W
Description Symbol Value Unit
Maximum fan
flow rate
F 62.03 m
3
/min
Fan power input P 38.9 W
Service value SV 1.59 (m
3
/min)/W
Standby power
consumption
P
SB
0.0 W
Fan sound power
level
L
WA
53.75 dB(A)
Maximum air
velocity
C 2.7 meters/sec
Measurement
standard for
service value
IEC 60879:1986 (corr. 1992)
Contact details
for obtaining
more information
OWIM GmbH & Co. KG
Stiftsbergstraße 1
74167 Neckarsulm
GERMANY
www.owim.com
