10 GB/IE/NI
Before use
Unpacking
Remove the packaging. Check if the product is
damaged.
Assembly
Accessory needed: Cross head screwdriver
Number of persons needed for assembly: 1 adult
Fig. Step
C
1. Remove the knurled screw [] from the
pole on the motor unit [9].
2. Place the pole on the base [].
3. Fasten with the knurled screw [].
D
Remove the 4 lock screws [] from the motor
unit [9].
E
1. Align the rear grille handle [5] upwards
and to the rear. Attach the rear grille [4]
to the motor unit [9].
2. Tighten with the 4 lock screws [].
F
1. Place the blade [2] on the motor shaft [6].
Insert the pins on the motor shaft into the
groove [3] on the rear of the blade.
2. Tighten the lock cap [1] on the motor shaft
[6] (direction of rotation: ).
Fig. Step
G
1. Remove the lock screw and the lock
nut [] from the front grille [].
2. Loosen the grille clips [] from the front
grille [].
3. Centre the hanging device [] of the front
grille [] on the rear grille [4].
NOTE: The 4 grille clips [] must fit over
the frame of the rear grille [4] and the
front grille [].
H
Insert and fasten the lock screw and the lock
nut []. Close the 4 grille clips [] over the
frame of the rear grille [4] and the front grille
[].
NOTE: The lock screw and the lock
nut [] are very small. Do not lose or drop
these fasteners.
Tilt adjustment
Loosen the knob [].
Adjust the tilt angle manually.
Tighten the knob [] again.
Do not perform the tilt adjustment when the
product is in operation.
