Simagic P1000 Series User Manual

P1000
USER MANUAL
06
2.2 Specifications
Product Name
P1000/P1000i
P1000F/P1000-FRS
P1000-RS/P1000i-RS
Resolution
12Bit (4096)【High
accuracy sensor】
12Bit (4096)【High
accuracy sensor】
12Bit (4096)【High
accuracy sensor】
USB connection
PC、SIMAGIC
wheelbase
PC、SIMAGIC
wheelbase
PC、SIMAGIC
wheelbase
Adjustable Travel
Supported
Supported
Supported
Adjustable Spring
Force Level
Clutch、Brake
Brake
Clutch、Brake
Hall angle sensor/
Loadcell sensor
• Throttle - Hall angle
sensor
• Brake-Hall angle
sensor/Loadcell
sensor
• Clutch-Hall angle
sensor
• Throttle - Hall
angle sensor
• Brake-Hall angle
sensor/Loadcell
sensor
• Throttle - Hall angle
sensor
• Brake-Hall angle
sensor/Loadcell
sensor
• Clutch-Hall angle
sensor
Loadcell sensor
100KG
100KG
100KG
Haptic Pedal
Reactor
Optional
Optional
Optional
Hydraulic Cylinder
Optional
Optional/Supported
Optional/Supported
Inverted
Installation
P1000i
Optional (Can't
change the oil
container after
invertion)
Optional/lncluded
Pedal Plate
Anodized Aluminum Alloy
Anodized Aluminum
Alloy
Anodized Aluminum
Alloy
Angle/Position
Adjustment
Supported
Supported
Supported
Adjustable
Linearity
Supported
Supported
Supported
Adjustable Brake
Force
Supported
Supported
Supported
Adjustable
Deadzones
Supported
Supported
Supported
Pedal control box
Included
Included
Included
Building Material
CNC Aluminum Alloy
CNC Aluminum Alloy
CNC Aluminum Alloy

Simagic P1000 Series Specifications

General

Material	Aluminum Alloy
Connectivity	USB
Load Cell	Yes
Compatibility	PC
Features	Adjustable pedal faces
Throttle Pedal	Included
Clutch Pedal	Included
