Sime MERIDIAN HE 30 C User Manual

7
MERIDIAN HE 30 C
Heat output
Nominal (80-60°C) kW 28.9
Nominal (50-30°C) kW 31.6
Reduced G20 (80-60°C) kW 5.9
Reduced G20 (50-30°C) kW 6.6
Reduced G31 (80-60°C) kW 7.6
Reduced G31 (50-30°C) kW 8.5
Heat input nominal kW 29.5
Heat input reduced G20/G31 kW 6.2/8.0
Max/min useful yield (80-60°C) % 98.0/95.1
Max/min useful yield (50-30°C) % 107.1/106.4
Useful yield at 30% of the load (40-30°C) %107.0
Termal efficiency (CEE 92/42 directive) 
Losses after shutdown to 50°C (EN 483) W89
Supply voltage V-Hz 230-50
Adsorbed power consumption W115
Electrical protection grade IP X4D
C.H. setting range °C 20/80
Water content boiler l 4.60
Maximum water head bar 3.0
Maximum temperature °C 85
Capacity of the heating expansion vessel l8
Pressure of the heating expansion vessel bar 1.0
D.H.W. setting range °C 10/60
D.H.W. flow rate (EN 625) l/min 13.4
Continuous D.H.W. flow rate ∆t 30°C l/min 14.4
Minimum D.H.W. flow rate l/min 2.2
D.H.W. pressure min/max bar 0.5/6.0
Exhaust fumes temper. at max flow rate (80-60°C) °C 79
Exhaust fumes temper. at min. flow rate (80-60°C) °C 67
Exhaust fumes temper. at max flow rate (50-30°C) °C 51
Exhaust fumes temper. at min. flow rate (50-30°C) °C 47
Smokes flow min/max kg/h 11/50
CO
2 at max/min flow rate G20 % 9.0/9.0
CO
2 at max/min flow rate G31 % 10.0/10.0
CE certification n° 1312CN5755
Category II2H3P
Type B23P-53P/C13-33-43-53-83
NOx emission class 5
Weight when empty kg 33.6
Main burner nozzle
Quantity nozzles n° 2
G20 nozzle diameter diversified ø 2.8/3.8
G31 nozzle diameter diversified ø 2.2/2.9
Consumption at maximum/minimum flow rate
G20 m
3
/h 3.12/0.66
G31 kg/h 2.29/0.62
Gas supply pressure G20/G31 mbar 20/37
1.3 TECHNICAL FEATURES

Sime MERIDIAN HE 30 C Specifications

General

Brand	Sime
Model	MERIDIAN HE 30 C
Category	Boiler
Language	English
