1.5 MAIN COMPONENTS (fig. 3)
KEY
1 Control panel
2 Condensate drain trap
3 C.H. sensor (SM)
4 Safety thermostat
5 Ignition electrode
6 Programming clock
7 Primary exchanger
8 Air release vent
9 Limit stat
10 Exhaust temperature sensor
11 Smoke chamber
12 Expansion vessel
13 Air inlet
14 Ionisation electrode
15 F an
16 Pressure relief valve
17 Air release vent
18 Pump
19 D.H.W. sensor (SS)
NOTE: Analogue pressure gauge
