Sim-Lab Rubber feet set
HARDWARE KIT
# Part QTY Note
B1 Rubber foot 4
B2 Bolt M8 X 20 DIN 7380-2 4
B3 Slot-Nut M8 4
Disclaimer: for some entries on this page, we supply more than required as spare
materials. Don’t worry if you have some leftovers, this is intentional.
GT1-EVO COCKPIT
PROFILE KIT
# Part QTY Note
A1 80X40 Length=1350mm 2
A2 80X40 Length=580mm 2
A3 80X40 Length=500mm 3
A4 80X40 Length=400mm 1
A5 80X40 Length=200mm 2
A6 40X40 Length=500mm 2
HARDWARE KIT
A7 Pedal deck 1
A8 Wheel deck 1
A9 Wheel deck pivot plate LEFT 1
A10 Wheel deck pivot plate RIGHT 1
A11 Corner bracket 40x40 24
A12 Corner bracket 40x40 cap 24
A13 Profile 80x40 end-cap 9
A14 Profile 40x40 end-cap 4
A15 Bolt M8 X 25 DIN 912 4
A16 Bolt M8 X 16 DIN 912 56
A17 Bolt M8 X 12 DIN 912 12 extra
A18 Bolt M6 X 20 DIN 912 12 extra
A19 Bolt M6 X 16 DIN 912 12 extra
A20 Bolt M5 X 25 DIN 912 12 extra
# Part QTY Note
A21 Washer M8 DIN 125-A 64
A22 Washer M6 DIN 125-A 24 extra
A23 Washer M5 DIN 125-A 24 extra
A24 Lock-Nut M8 DIN 985 4
A25 Lock-Nut M6 DIN 985 12 extra
A26 Lock-Nut M5 DIN 985 12 extra
A27 Slot-Nut M8 56
