BASSINET FRAME DISASSEMBLY
Fig. 5B
Place front and back side buttons on the support tube
and lift upward to remove. Repeat on opposite side.
Left Side
Frame Stand
Right Side
Frame Stand
Bottom Cross
Support Bar
Fig. 5D
Fig. 5C
3
Using the wrench, unscrew screws on left and right
side frame (Fig. 5C).
Use wrench to remove nut & bolt to remove nut & bolt
by turning counter-clockwise (Fig. 5A)
Pull upward on tube to remove (Fig. 5B).
Pull frame stand outward to remove. Repeat on opposite
side (Fig. 5D).
5
Fig. 5A
Use the wrench to remove
nut & bolt by turning
counter- clockwise
Nut
Bolt
