7 - 3
7 Foot Controls Repair
Foot Controls Diagram - Gear Models
1 1 SPRING, Return
2 A/R WASHER, 3/4
3 1 PULLEY, Idler
4 1 SPRING, Idler
5 1 KLIPRING, 1/2
6 1 PAD, Pedal
7 1 LEVER, Idler, Pulley
8 1 ROD, Clutch, Rear
9 1 ROD, Brake
10 1 ROD, Clutch, Front
11 1 LEVER, Clutch
12 1 BRACKET, Shift
13 1 ROD, Shift, Front
14 1 BAR, Shift, Rear
15 1 TORSION BAR
16 2 BRACKET, Torsion Bar
17 1 PIVOT, Brake
18 1 KLIP RING, 3/8
19 1 SPRING, Compression
20 2 CLEVIS, Idler, Bracket
21 1 PIVOT SHAFT ASSY.
22 1 SPACER, Pivot
23 2 SPACER
24 1 LOCKWASHER, 1/4
25 2 LOCKWASHER, 5/16
26 2 NUT, Hex, 5/16-18
27 6 COTTER PIN, 3/32 x 3/4
28 4 WASHER, Plain
29 3 WASHER, Plain, 5/16
30 2 NUT, Hex, Nylon Lock, 5/16-18
31 1 WASHER, Plain, 17/64 x 5/8 x 3/64
32 1 SCREW, Hex Hd., 1/4-28 x 5/8
33 2 WASHER
34 2 WASHER, Plain, 1/2
35 4 SCREW, Hex Hd., Flange, Taptite,
5/16-18 x 1/2
36 1 SCREW, Hex Hd., Flange, Taptite,
1/4-20 x 5/8
37 1 NUT, Hex, Flange Lock, 3/8-16
38 1 CARRIAGE BOLT, 5/16-18 x 1
39 1 CARRIAGE BOLT, 5/16-18 x 2-3/4
40 1 CARRIAGE BOLT, 5/16-18 X 1-1/4
41 2 KEY
Ref. Qty. Description Ref. Qty. Description
Foot Controls - Gear Models
