SIMPLIHOME Lowry - Step 5: Attaching Shelves to Left Side Panel

Step 5
C
D
E
BL
Front / Avant
Front /
Avant
Front / Avant
Front / Avant
1. Align Wood Dowels with guide holes on
Left Side BL and attach Middle Shelf D
and Bottom Shelf C to Left Side BL .
1
1
D
C
BL
Front / Avant
Front / Avant
Front / Avant
Front / Avant
1
12
2. Use three Allen Key Screws 1 to attach each part C , D through guide holes.
3. Use Allen Key 12 to tighten Screws. Do not over-tighten.
15
Model # AXCLRY42-DCBAssembly
