SIMPLIHOME Lowry - Hardware Identification

.
1
.
9
.
11
.
3
.
5
.
7
.
2
.
4
.
8
.
6
.
10
.
12
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
ALLEN KEY
QTY 1
ALLEN KEY SCREW
M6 X 30mm
QTY 24
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 27
WOOD DOWEL
Ø8 X 30mm
QTY 14
SHELF SUPPORT
QTY 12
MAGNET AND PLATE
QTY 2 SETS
PHILLIPS SCREW
M3 X 15mm
QTY 8
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
ALLEN KEY BOLT
M8 x 20 mm
QTY 12
LOCK WASHER
Ø12 / Ø8 x 1.5 mm
QTY 12
WASHER
Ø19 / Ø8 x 1 mm
QTY 12
ADJUSTABLE HINGE
QTY 4 SETS
PHILLIPS SCREW
M4 X 15mm
QTY 24
.
13
Hardware Description
9
Model # AXCLRY42-DCBPre-Assembly Information
