Master Switch
Individual
Switches
Sub Group Switches
Example: By following the three basic rules illustrated on the front of this sheet, you can
create almost any combination with the Hertz technology. Everything from individual
switching and sub grouping to a master control can be accomplished without the use of
external controls. The ability to parallel wire the Hertz operators makes it easy to wire.
Simply supply power to the electric operator and program the wireless transmitter to the
motor or motors of choice and you are done.
For more information about other options available, please consult a SIMU
representative for more details.
Hz 2 Type 5 / DMI Operator
Basic Rules and Scenarios
