Simu Hz 2 - Page 18

Operators
Hz Type 5
Bracket Accessories
Item Reference Description
Standard Bracket
- 30mm spacing / counter sunk holes
- Attaches to wall plate 850066 or 850067
- Zinc Plated
520076
Shade Bracket
- 30mm spacing / 1/4” US Threaded holes
- Attaches to wall bracket: 520210
- Gold Zinc Plated
252527
Shutter Bracket
- Maxi side frame bracket 100x100mm
- Requires side frame center pin to be removed
- Gold Zinc Plated
520187
Shutter Bracket
- Mini side frame bracket 80x80mm
- No center pin removal required
- Gold Zinc Plated
Bracket Fitting Set
- Type 5 bracket fitting set
520049
850365
