Simu Hz 2 User Manual

Motor Selection Guide
For Hz Type 5 Operators
kg.
lb.
9
20
18
40
27
60
36
80
45
100
55
120
64
140
73
160
82
180
91
200
100
220
109
240
118
260
127
280
136
300
145
320
155
340
164
360
173
380
Model
Type
505
510
515
525
530
535
550
25(lbs.)
41(lbs.)
62(lbs.)
103(lbs.)
123(lbs.)
143(lbs.)
205(lbs.)
78mm (3.0 inch) TUBE DIAMETER
-The listed charts reflects the recommended 30% security
factor that is used for most applications.
-Shutters more than 9 feet high: add 10% to the effective
load for every additional 3 feet.
-Double span shutters: add 20% to the effective load to
be lifted.
kg.
lb.
9
20
18
40
27
60
36
80
45
100
55
120
64
140
73
160
82
180
91
200
100
220
109
240
118
260
127
280
136
300
145
320
155
340
164
360
173
380
Model
Type
505
510
515
525
530
535
550
22(lbs.)
38(lbs.)
57(lbs.)
95(lbs.)
114(lbs.)
132(lbs.)
189(lbs.)
85mm (3.25 inch) TUBE DIAMETER
R
4
