SINAMICS G120 - Page 116

SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Spare parts
Replacement fan
4/116
Siemens D 11.1 · 2009
4
■ Overview
The Power Module fans are designed for extra long service life.
Replacement fans can be ordered for special applications.
■ Selection and ordering data
Rated power SINAMICS G120
PM240 Power Module
Replacement fan
kW hp Type
6SL3224-...
Frame size
and
number of
fans
Order No.
380 … 480 V 3 AC
0.37 0.50 0BE13-7UA0 FSA,
1fan
6SL3200-0SF01-0AA0
(includes
1 replacement fan)
0.55 0.75 0BE15-5UA0
0.75 1.0 0BE17-5UA0
1.1 1.5 0BE21-1UA0
1.5 2 0BE21-5UA0
2.2 3 0BE22-2 . A0 FSB,
2 fans
1)
3.0 4 0BE23-0 . A0
4.0 5 0BE24-0 . A0
7.5 10 0BE25-5 . A0 FSC,
2 fans
1)
6SL3200-0SF03-0AA0
(includes
1 replacement fan)
11.0 15 0BE27-5 . A0
15.0 20 0BE31-1 . A0
18.5 25 0BE31-5 . A0 FSD,
2fans
6SL3200-0SF04-0AA0
(includes
2 replacement fans)
22 30 0BE31-8 . A0
30 40 0BE32-2 . A0 6SL3200-0SF05-0AA0
(includes
2 replacement fans)
37 50 0BE33-0 . A0 FSE,
2fans
6SL3200-0SF04-0AA0
(includes
2 replacement fans)
45 60 0BE33-7 . A0 6SL3200-0SF05-0AA0
(includes
2 replacement fans)
55 75 0BE34-5 . A0 FSF,
2fans
6SL3200-0SF06-0AA0
(includes
2 replacement fans)
75 100 0BE35-5 . A0
90 125 0BE37-5 . A0
6SL3200-0SF07-0AA0
(includes
2 replacement fans)
110 150 0BE38-8UA0
6SL3200-0SF08-0AA0
(includes
2 replacement fans)
132 200 0BE41-1UA0
160 250 0XE41-3UA0 FSGX,
2fans
6SL3362-0AG00-0AA1
(includes
2 replacement fans)
200 300 0XE41-6UA0
250 400 0XE42-0UA0
new
Rated power SINAMICS G120
PM250 Power Module
Replacement fan
kW hp Type
6SL3225-...
Frame size
and
number of
fans
Order No.
380 … 480 V 3 AC
7.5 10 0BE25-5AA0 FSC,
2 fans
1)
6SL3200-0SF03-0AA0
(includes 1 replacement
fan)
11.0 15 0BE27-5AA0
15.0 20 0BE31-1AA0
18.5 25 0BE31-5 . A0 FSD,
2fans
6SL3200-0SF04-0AA0
(includes 2 replacement
fans)
22 30 0BE31-8 . A0
30 40 0BE32-2 . A0 6SL3200-0SF05-0AA0
(includes 2 replacement
fans)
37 50 0BE33-0 . A0 FSE,
2fans
6SL3200-0SF04-0AA0
(includes 2 replacement
fans)
45 60 0BE33-7 . A0 6SL3200-0SF05-0AA0
(includes 2 replacement
fans)
55 75 0BE34-5 . A0 FSF,
2fans
6SL3200-0SF06-0AA0
(includes 2 replacement
fans)
75 100 0BE35-5 . A0
90 125 0BE37-5 . A0 6SL3200-0SF08-0AA0
(includes 2 replacement
fans)
Rated power SINAMICS G120
PM260 Power Module
Replacement fan
kW hp Type
6SL3225-...
Frame size
and
number of
fans
Order No.
660 … 690 V 3 AC
11.0 15 0BH27-5 . A1 FSD,
2fans
6SL3200-0SF11-0AA0
(includes 2 replacement
fans)
15.0 20 0BH31-1 . A1
18.5 25 0BH31-5 . A1
30 40 0BH32-2 . A1 FSF,
2fans
6SL3200-0SF07-0AA0
(includes 2 replacement
fans)
37 50 0BH33-0 . A1
55 75 0BH33-7 . A1
new
1)
Recommended: Even if only one fan on the Power Module is defective,
it is advisable to replace both. In this case, the order quantity must be
doubled.
