SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
PM240 Power Modules –
0.37 kW to 250 kW (0.5 hp to 400 hp)
4/35
Siemens D 11.1 · 2009
4
■
Integration
Maximum permissible cable lengths from the motor to the
inverter when using output reactors or sine-wave filters
depending on the voltage range
The following load-side power components are optionally avail-
able in the appropriate frame sizes and result in the following
maximum cable lengths:
Derating data
The following inverter output currents can still be implemented
for long motor cables without output reactor and sine-wave filter.
Derating for PM240 Power Modules, frame sizes FSA to FSF for
shielded motor cables. From frame size FSD and higher, only the
particular main Power Module types were tested. The values
also apply to the other Power Modules of the particular frame
size.
– Not possible
Maximum permissible motor cable lengths (shielded/unshielded) in m
Frame sizes
FSA FSB FSC FSD FSE FSF FSGX
PM240 Power Module with integrated brake chopper without inte-
grated brake
chopper
Available frame sizes ✓ ✓ ✓ ✓ ✓ ✓ ✓
Without output reactor/sine-wave filter 50/100 50/100 50/100 50/100 100/100 150/150 300/450
With optional output reactor
• at 380 V (–10 %) to 400 V 3 AC 150/225 150/225 150/225 200/300 200/300 200/300 300/450
• at 401 V to 480 V (+10 %) 3 AC 100/150 100/150 100/150 200/300 200/300 200/300 300/450
With optional sine-wave filter
• at 380 V (–10 %) to 400 V 3 AC 150/225 150/225 150/225 200/300 200/300 200/300 300/450
• at 401 V to 480 V (+10 %) 3 AC 100/150 100/150 100/150 200/300 200/300 200/300 300/450
Rated power
(at I
H
)
Frame size Base load
current I
H
Rated current
I
rated
Motor con-
nection cross-
section
Current derating
of the output current as a % of the base load current
for the cable lengths (MOTION-CONNECT)
kW hp A A mm
2
50 m 100 m 150 m 200 m
0.37 0.50 FSA 1.3 1.3 2.5 100 % – – –
0.55 0.75 FSA 1.7 1.7 2.5 100 % – – –
0.75 1.0 FSA 2.2 2.2 2.5 100 % – – –
1.1 1.5 FSA 3.1 3.1 2.5 100 % – – –
1.5 2.0 FSA 4.1 4.1 2.5 100 % – – –
2.2 3.0 FSB 5.9 5.9 6 100 % 60 % – –
3.0 4.0 FSB 7.7 7.7 6 100 % 60 % – –
4.0 5.0 FSB 10.2 10.2 6 100 % 70 % – –
5.5 7.5 FSC 13.2 18 10 100 % 70 % 45 % –
7.5 10 FSC 19 25 10 100 % 90 % 80 % –
11.0 15 FSC 26 32 10 100 % 90 % 80 % –
22.0 30 FSD 45 60 35 100 % 95 % 90 % 85 %
37.0 50 FSE 75 90 35 100 % 100 % 95 % 90 %
75.0 100 FSF 145 178 95 100 % 100 % 100 % 95 %
