SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
PM240 Power Modules –
0.37 kW to 250 kW (0.5 hp to 400 hp)
4/40
Siemens D 11.1 · 2009
4
■ Technical specifications
Line supply voltage
380…480V 3AC
PM240 Power Modules
Without integrated line filter 6SL3224-
0BE33-7UA0
6SL3224-
0BE34-5UA0
6SL3224-
0BE35-5UA0
6SL3224-
0BE37-5UA0
6SL3224-
0BE38-8UA0
6SL3224-
0BE41-1UA0
With integrated line filter 6SL3224-
0BE33-7AA0
6SL3224-
0BE34-5AA0
6SL3224-
0BE35-5AA0
6SL3224-
0BE37-5AA0
– –
Output current
at 50 Hz 400 V 3 AC
• Rated current I
rated
1)
A 90 110 145 178 205 250
• Base load current I
L
1)
A 90 110 145 178 205 250
• Base load current I
H
2)
A 75 90 110 145 178 205
• I
max
A 150 180 220 290 308 375
Rated power
• based on I
L
kW (hp) 45 (60) 55 (75) 75 (100) 90 (125) 110 (150) 132 (200)
• based on I
H
kW (hp) 37 (50) 45 (60) 55 (75) 75 (1oo) 90 (125) 110 (150)
Rated pulse frequency
kHz 4 4 4 4 2 2
Efficiency
η >0.97 >0.97 >0.97 >0.97 >0.97 >0.97
Power loss
(at rated current)
kW 1.21 1.42 1.93 2.31 2.43 2.53
Cooling air requirement m
3
/s 2 × 0.055 0.15 0.15 0.15 0.15 0.15
Sound pressure level L
pA
(1 m)
dB <62 <60 <60 <65 <65 <65
24 V DC power supply
for Control Unit
A 1 1 1 1 1 1
Rated input current
3)
• with line reactor A 94 115 151 186 210 250
• without line reactor A 105 129 168 204 245 299
Max. length of cable to
braking resistor
m 15 15 15 15 15 15
Line supply connection
U1/L1, V1/L2, W1/L3
M6 screw studs M8 screw studs M8 screw studs M8 screw studs M8 screw studs M8 screw studs
• Conductor cross-section mm
2
10 … 50 25 … 120 25 … 120 25 … 120 25 … 120 25 … 120
Motor connection
U2, V2, W2
M6 screw studs M8 screw studs M8 screw studs M8 screw studs M8 screw studs M8 screw studs
• Conductor cross-section mm
2
10 … 50 25 … 120 25 … 120 25 … 120 25 … 120 25 … 120
DC link connection,
connection for the braking
resistor
DCP/R1, DCN, R2
M6 screw studs M8 screw studs M8 screw studs M8 screw studs M8 screw studs M8 screw studs
• Conductor cross-section
mm
2
10 … 50 25 … 120 25 … 120 25 … 120 25 … 120 25 … 120
PE connection
On housing with
M6 screw
On housing with
M8 screw
On housing with
M8 screw
On housing with
M8 screw
On housing with
M8 screw
On housing with
M8 screw
Motor cable length
4)
, max.
• Shielded m 100 150 150 150 150 150
• Unshielded
m 100 150 150 150 150 150
Degree of protection
IP20 IP20 IP20 IP20 IP20 IP20
Dimensions
• Width mm 275 350 350 350 350 350
•Height
- without integrated filter mm 499 634 634 634 634 634
- with integrated filter mm 635 934 934 934 – –
•Depth
- without Control Unit mm 204 316 316 316 316 316
- with Control Unit mm 260 372 372 372 372 372
Frame size FSE FSF FSF FSF FSF FSF
Weight, approx.
• without integrated filter kg 16 36 36 36 39 39
• with integrated filter kg 23 52 52 52 – –
1)
The rated output current I
rated
and the base load current I
L
are based on
the duty cycle for light overload (LO).
2)
The base load current I
H
is based on the duty cycle for high overload (HO).
3)
The input current depends on the motor load and line impedance. The
input currents apply for a load at rated power (based on I
rated
) for a line
impedance corresponding to u
K
= 1 %. These current values without line
reactor are stamped on the rating plate of the Power Module.
4)
Max. motor cable length 25 m (shielded) for PM240 Power Modules with
integrated line filter to maintain the limit values of EN 61800-3 Category C2.
