SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
SINAMICS G120 standard inverters
4/6
Siemens D 11.1 · 2009
4
■ Design
Power and DC link components which are optionally avail-
able depending on the Power Module used
The following line-side power components, DC link components
and load-side power components are optionally available in the
appropriate frames sizes for the Power Modules:
U = Base component
S = Lateral mounting
I = Integrated
– = Not possible
F = Power Modules available with and without integrated class A filter
Frame size
FSA FSB FSC FSD FSE FSF FSGX
PM240 Power Module with integrated brake chopper without inte-
grated brake
chopper
Available frame sizes ✓ ✓ ✓ ✓ ✓ ✓ ✓
Line-side power components
Line filter, class A U F F F F F/S
3)
S
3)
Line filter, class B U U U – – – –
Line reactor U U U U U S S
DC link components
Braking resistor U U S S S S S
Braking Module – – – – – – I (Option)
Load-side power components
Output reactor U U U S S S S
Sine-wave filter U U U S S S S
PM250 Power Module with line-commutated energy recovery
Available frame sizes – – ✓ ✓ ✓ ✓ –
Line-side power components
Line filter, class A – – I F F F –
Line filter, class B – – U – – – –
Line reactor
1)
– – –
1)
–
1)
–
1)
–
1)
–
DC link components
Braking resistor
2)
– – –
2)
–
2)
–
2)
–
2)
–
Load-side power components
Output reactor – – U S S S –
Sine-wave filter – – U S S S –
PM260 Power Module with line-commutated energy recovery and integrated sine-wave filter
Available frame sizes – – – ✓ – ✓ –
Line-side power components
Line filter, class A – – – F – F –
Line filter, class B – – – – – – –
Line reactor
1)
– – – –
1)
– –
1)
–
DC link components
Braking resistor
2)
– – – –
2)
– –
2)
–
Load-side power components
Output reactor – – – – – – –
Sine-wave filter – – – I – I –
1)
A line reactor is not required and must not be used in conjunction with a
PM250 or PM260 Power Module.
2)
Line-commutated energy recovery is possible in conjunction with a PM250
or PM260 Power Module. A braking resistor cannot be connected and is
not necessary.
3)
PM240 FSF Power Modules, from 110 kW (150 hp) and higher and FSGX
are only available without an integrated class A filter. An optional class A
line filter for side mounting is available instead.
