1
01252226 01252220
1
2 Rear Case assy
222023014 222023045
1
3 Evaporator Pipe Cover
06122001 06122001
1
4 Drainage Pipe
05230014 0523001401
1
5 Pipe Clamp
24242001 24242001
1
6 Cross Flow Fan
10352398 10352001
1
7 Fan Bearing 76512210 76512210 1
8 Ring of Bearing
76512203 76512203
1
9 Water Tray Cover
76712012 76712012
1
10 Water Tray
20182004 20182006
1
11 Connecting Lever 1
11582004 10582002
1
12 Connecting Lever 2
11582005 10582003
1
13 Manual Lever
10582001 10582001
2
14 Evaporator Assy
010021114 01002070
1
15 Evaporator Supporter 24212035 24212035 1
16
20002685 200026103
1
17 Screw Cover
242520011 242520011
3
18 Front Panel
20002811S 20002818S
1
19 Filter 11122006 11122002 2
20 Air Cleaner holder
/ /
/
21 Air Cleaner A
/ /
/
22 Guide Louver 261120042 105120016 1
23 Remote Controller YK1F
30510044 30510044
1
24 Guide Louver Bearing
10542011 10542011
3
25 Air Cleaner B
/ /
/
26 Tube Sensor
390000591 390000591
1
27 Sensor Insert
42020063 42020063
1
10512002
10
10512002
12
29 Stepping Motor MP24BA
15212107 15212107
1
30 Motor FN8G-PG 15012076 150120761 1
31 Motor Clamp
26112014 26112014
1
32 Wire Clip
/ /
/
33 Electric Box Cover 2
20112048 20112050
1
Main Board M504F1J 1
Main Board M504F2J
30135070 30135070
1
35 Room Sensor
390001912 390001912
1
36 Jumper Cap 4202300104 4202300105 1
37
46010014 46010014
1
38 Power Cord
400220111 400220112
1
39 Connecting Cable
40020540 400205401
1
40 Terminal Board
42010262 42010262
1
41 LED Board DBL3A
30540021 30540021
1
42 Transformer 41X26.5G
43110236 43110236
1
43 Electric Box
20112046 20112045
1
44 Electric Box Cover 20112047S 20112049S 1
45 Cable Clamp
70482001 71010103
1
34
QtyNo Description
28
Swing Louver
Part Code
The above data are subject to be changed without notice.
ASH-09AP
ASH-12AP
Wall-Mounting Grame
Front Case
Fuse
To Next Page
