Sinclair ASH-09AP - Page 36

1 Front Grill 1
2 Axial Flow Fan 1
3 Front Plate 1
4 Metal Base 1
5 4-way valve 1
6 4-way valve coil 1
7
Compressor
1
8
Overload Protector
1
9 Nut with washer 3
10 Capillary Assy 1
11 Handle 1
12 Gas Valve 3/8 1
13 Liquid Valve 1/4 1
14 Valve Support 1
15 Right Side Plate 1
16 Wiring clamp plate 1
17 Wiring clamp cover 1
18 Terminal Board 1
19 Electric Plate 1
20 Comp Capacitor 1
21 Capacitor Clamp 1
22 Fan Capacitor 1
23 Terminal Board 1
24 Isolation Sheet Assy 1
25 Condenser Assy 1
26 Rear Grill 1
27 Top Cover 1
28 Motor Support Assy 1
29 Drainage Connecter 1
30 Motor 1
31 Backstop 1
06123401
15013156
01793005
01113017
11123204
01253027
01703054
02143014
33010020
42011103
01233103
24253002
42010254
01403012
33000018
07100003
01713424
01303151
24253001
70310014
03003918
26233101
07100005
430004022
43000400
00103072
00183008
01473004
10333005
01533024
01203725P
QtyNo Description
Part Code
The above data are subject to be changed without notice.
ASH-09AP
