Sinclair ASH-09AP - Page 38

1 Front Grill 1
2 Nut M6 1
3 Axial Flow Fan 1
4 Front Plate 1
5 Metal Base 1
6 4-way Valve 1
7 4-way Valve Coil 1
Compressor 1
Overload Protector 1
Compressor Gasket 3
9 Nut with Washer 3
10 Valve Support 1
11 Right Side Plate 1
12 Valve 1/4" 1
13 Valve 1/2" 1
14 Handle 1
15 Tube Sensor /
16 Terminal Board 1
17 Electric Plate Assy 1
18 Capacitor 1
19 Capacitor 1
20 Terminal Board 2-8 1
21 AC Contactor /
22 Isolation Sheet 1
23 Rear Grill 1
24 Top cover plate 1
25 Condenser Assy 1
26 Motor Support 1
27 Motor 1150130671
11123205
01253443
01103987
01703020
33010026
42011103
None
01233417
None
42010254
01403117
33000017
01303048
07100003
07100006
26233433
00180036
自带
70310014
01713041
0120362001P
430004022
43000400
00103025
8
QtyNo Description
Part Code
22413431
70310131
10333414
01533012
The above data are subject to be changed without notice.
ASH-12AP
