Model W(mm) H(mm) D(mm)
ASH-09AP 710 250 180
ASH-12AP 770 250 180
Air inlet grill
Left Tube-exit Sign Top View Right Tube-exit Sign
Rear View
Ceiling
１６
Overall and Installing Dimension of Indoor Unit
