Singer 1507WC - Winding the Bobbin

18
1
2
3
4
5
678
9
Winding the bobbin
GB
- Place thread and spool holder onto spool pin (1).
- For smaller spools of thread place spool holder with
small side next to spool (2).
- Wind thread anticlockwise around bobbin winder
tension discs (3).
- Thread bobbin as illustrated and place on spindle
(4).
- Push bobbin to right (5).
- Hold thread end (6).
- Step on foot control pedal (7).
- Cut thread (8).
- Press bobbin to left (9) and remove.
Please Note:
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the hand wheel
will not turn. To start sewing, push the bobbin winder
spindle to the left (sewing position).
