Grinding Head for
956, 957 & 958
Furnish Machine and Serial Number When Ordering Parts
Fig- Part
ure No. Name
1 54437 Stop-Long
2
09095 Screw-Flat Hd. Socket
3/8"-16x1"
3
07225 Screw-Phil. Pan Hd.
4' 07190
5 35234
6 54438
7 35350
8 24171
9 81
10 54530
11 08275
12 35357
13 11422
11462
14 30734
15 04248
04300
16 30744
17 41298
18 10281
19
20
#10-32x3/8" (3)*
Bolt-Thru (4)*
Washer (4)*
Stop-Short
Cover-Right
End
Flange-Grinding Wheel
Wheel-Grinding
Flange-Inner
Screw-Phil.
Rd. Hd . 1/4"-20x3/8"
Deflector
End Shield (Right End)(Up to Ser. "B")
(Ser. No's. Starting w/"B")
Adaptor- Tube (2)*
Hose-Coolant
(Up to Ser . "B")
(Ser . No 's. Starting w/"B")
Clamp-Hose (4)*
Washer-
Thrust
Bearing-Ball (2)*
Rotor & Shaft
(Information Available Upon Request)
Assy . -Stator & Base
(Information Available Upon Request)
21 04252 Ring-"0" (2)* (Up to Ser. "B")
22 53692 Assy.-CoolantTube (Up to Ser. "B")
23 06673 Screw (#8-32x3/8") (2)*
24 35316 Box-Conduit
Fug- Part
ure No. Nama
34 35373 Lockplate
35 54532 Spacer-Outer (Early Models)
36 11423 End Sheild (Left End) (Up to Ser . "B")
11461 (Ser. No's . Starting w/"B ")
37 08176 Screw-Flat Hd .
1/4"-20x1-1/2" (2)*
38 09635 Nut-Hex Jam 1 /2"- 20 (Up to Serial " B")
09656R Nut-Hex 5/8-18 (Start w/" B")
42 18798 Assy .- Fiexiblelight(UptoSeriai"B")
(Incl. Fig . 38)
14854 Tubing-Insulation (Up to Ser. "B")
28153 Light (Ser. Start with "B")
44 54983-1 Coolant Tube (Right)
54983-2 Coolant Tube (Left)
45 30731 Valve (2)*
46 09462 Nut#10 -32( 4)*
47 54531 Flange-Inner
48 176 Wheel-?'' Grinding (For General Grinding)
177 Wheel-?'' Grinding (For Grinding Stellite)
49 54407 Flange-Outer
50 09096 Screw-Flat Hd . Socket
3/8" - 16x1" L.H. Thd .
51 35351 Cover-Left End
52 35352 Shield-Air
53 08279 Screw-Phil. Rd. Hd.
1/4"-20x1/2"
54 04000 Tee-Coolant (Ser . No's. Starting w/"B " )
55 04248 Hose-Coolant (Ser. No 's. Starting w/"B")
18988 Bulb-Light (230V)
18911 Bulb-Light (115V)
25 05014 Gasket-Conduit Cover
56 63341 Assy.-Ciamp Post & Plate (Ser. No's . Starting with "B")
26 14856 Bushing-Strain Relief (Up to Ser. "B")
27 05012 Gasket-Conduit Box
28 09656R Nut-Hex. Jam5/8"-18(UptoSer. "B")
09590 Nut-(Ser. No's. Starting w/"B")
29 25894 Washer 21 /32"x1-1 /4"x3/32" (Up to Ser. "B")
00 25158 Washer(Ser. No's. Startingw/"B")
30 09830 Washer-Shakeproof Lock 1 /4" (4)*
31 08120 Screw- Truss Hd. 1/4 "-20x1 /2" (4)*
32 11439 Plate-Base
33 53643 Assy .-Ciamp Post & Plate (Up to Ser. "B")
COMPLETE ASSY.
53686 Assy. -Grinding Head (Everything except 15,
16,28,29,33 & Light Bulb)
(Specify Voltage & Phase) (Up to Ser. "B")
63347 (Ser . No's . Starting w/"B")
53693 Assy .-Grinding Head (Incl. Figs . 4,5,
13, 17-25, 27' 30-32, 34-37 & 46.)
*Order Quantity As Needed
