DISC
27
7.5 Replacing the blade holders, mower blade and
screw
The blade holder gets worn out during the work. When
the holder gets worn out for width of 2 mm, it must be
replaced with new one.
If the sliding screw surface wear aut to max. 1,9 mm,
replace the screw (see picture).
If the blade hole increased to max. 21 mm, replace the
mower blade (see picture).
DISC 220 F ALP
DISC 260 F ALP
DISC 300 F ALP
7.6 Replacement of safety pins on individual
disks
Hitting an obstruction may lead to a large load on the
individual disk. To prevent possible damage to disks
and ridge caps, buffers are installed. If the protective
caps are cut, they can be replaced quickly and easily.
– Repair works, maintenance, periodical
overhauls, cleaning and elimination of
funtctional disturbances must be
performed with the switched off drive
and stand still engine! Remove the
ignition key!
