Sipromac 300 - Page 29

004C3857
S.L.
1
M
300 @ 350D
REAR PANNEL PRE-ASS'Y
13-11-22
004C3857
MACHINE
PART
ITEM
MAT.
CNC
DWG BY
APP. BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
± 0.5
± 0. 5
INCH
± 0.004"
± 0.020"
± 0.020"
N.T.S.
NO.
LET.
MODIFICATION
DATE INT.
15~
ITEM PART # DESCRIPTION QT.
1 001C6141 REAR PANEL 1
2 127-0115 STICKER ELEC. CONN. 15A 2-1/2'' X 3-3/4'' 1
3 051-0740 WASHER 1/4" FLAT S/S 4
4 051-0185 SCREW 1/4-20x 1/2"PAN PHIL S/S 4
1
109~
2
43
