NAMES OF MAJOR PARTS
1Lifting lever
2Thread take-up cover
5Bobbin winder
4Cotton stand
3Power switch
6Operation panel
7Machine pulley
8Motor cover
9Oil gage window
10Reverse seam switch button Needle lever
release button(245,275)
11Oil pan
各部件名稱 NAMES OF MAJOR PARTS
1)壓腳扳手
2)挑線桿防護罩
5)梭芯繞線裝置
4)線架
3)電源開關
6)操作盒
7)手輪
8)電機罩
9)油標
10)倒縫開關按鈕 針桿分離按鈕 (245,275)
11)油盤
P2
