DART SEPT ‘12
3
Contents
Page
Declaration of Conformity ..................................................................................................................................................... 2
Serial Numbers ..................................................................................................................................................................... 2
Introduction ........................................................................................................................................................................... 2
Technical Data ...................................................................................................................................................................... 3
Important Safety Instructions ........................................................................................................................................... 3 - 4
Operating Instructions .......................................................................................................................................................... 5
Routine Maintenance............................................................................................................................................................ 6
Tines ..................................................................................................................................................................................... 7
Parts Listings ................................................................................................................................................................. 8 - 12
Notes .................................................................................................................................................................................. 13
Technical Data
Model DART
Width (mm) 680
Length (mm) 1550
Height (mm) 1180
Weight (Kg) 217
Working Width (mm) 16” (430mm)
Engine GX160
Wheels - Rear
Wheels - Front
(2) 13 x 6.50-6 slick
(2) 260 x 85-3.00-4 ribbed
Hand Arm Vibration (m/sec
2
) 9.5
Measured Sound Power Level (dB(A)) 80
Guaranteed Sound Power Level (dB(A)) 98
Introduction
Important Safety Instructions
NEVER
• carry out adjustments with the engine running.
ALWAYS
• Read the operating instructions carefully and understand the controls before commencing work.
• Be extra careful to avoid spillage, when using petrol or diesel fuel. DANGER no smoking or naked lights
• Use safety guards and make sure they are correctly in position. They are supplied for your protection
•
Visually check machines before starting work for damage or wear to working parts such as blades,tines or loose fasteners
• Respect powered machines. Always keep hands and feet clear of moving parts and remember that tine cylinders or
drums can continue to rotate even after the power unit is switched off
• Switch off the power before making adjustments or repairs and never lift or carry a machine whilst any parts are
Moving
EYE PROTECTION
In dry, dusty or windy conditions it may be necessary to wear eye protection to protect your eyes from ying debris.
FIRE HAZARD
ALWAYS CLEAN THE MACHINE. REMOVE ALL DEBRIS FROM AROUND THE ENGINE. BLOCKED
ENGINE COOLING FINS CAN CAUSE THE ENGINE TO OVERHEAT
CAUTION
READ THE INSTRUCTIONS CAREFULLY AND ALSO THE SEPARATE INSTRUCTION
DETAILS ON THE ENGINE.
To Next Page
