PROFLAME 2 BATTERY HOLDER USE AND INSTALLATION INSTRUCTIONS
4
CAUTION
Property Damage Hazard.
Excessive heat can cause property damage.
The appliance can stay lit for many hours. Turn off the appliance if it is not going to be
attended for any lenght of time.
Always place the Transmitter where children can not reach it.
WARNING
Fire Hazard. Can cause severe injury or death
The Receiver causes ignition of the appliance. The appliance can turn on suddenly. Keep
away from the appliance burner when operating the remote system or activating manual
bypass of the remote system.
LOW BATTERY POWER DETECTION
The life span of the Proflame 2 IFC batteries depends on various factors: quality of the batteries
used, the number of ignitions of the appliance, the number of changes to the room thermostat set
point, etc.
When the Proflame 2 IFC batteries are low, two (2) “beeps” will be emitted from the Proflame 2 IFC
every time it receives a command from the Transmitter. This is an alert for a low battery condition
for the Proflame 2 IFC. When the batteries are replaced one (1) “beep” will be emitted from the
Proflame 2 IFC when a command is sent by pressing any key on the transmitter (for example the
ON / OFF key), see "Initialization of The System".
Preliminary check of the Battery Holder
Operations to be done, before switching on the Remote Control:
•
Check that the wiring harness connections are made correctly between the Proflame 2 Battery
holder and the Proflame 2 Integrated Fireplace Control (IFC). If 0.584.920 and 0.584.922 wire
harness are used, connect 0.584.920 J1 terminal to 0.584.922 J1 terminal, see Fig. 2.
Initializing the Transmitter/Receiver link System for the first time
Install the 4 AA batteries into the Proflame 2 Battery holder battery bay. Note the polarity of the
battery and insert into the battery bay as indicated on the cover (+/-). Place the 3 position slider
switch in the “Remote” position. (Fig. 1) Insert the end of a paper clip or similar object into the
hole marked "PRG" on the Receiver front cover. (fig 1) The Receiver will “beep” three (3) times
to indicate that it is ready to synchronize with a Transmitter. Install the 3 AAA type batteries in
the Transmitter battery bay, located on the base of the Transmitter and push the On button. The
Receiver will “beep” four times to indicate the Transmitter’s command is accepted and set to the
particular code of that Transmitter. The system is now initialized.
