Frontpanel
The frontpanel describes the corresponding LED indications and port functionality.
LED Description
POWER Lights up when powered ON. Blinks
on TEST/RESET
Wan Lights up when a ADSL cable is
connected.
Online
Lights up when internet connection is
UP.
WLAN Lights up in Blue when WLAN is
enabled. Blinks on traffic
WPS Blinks when WPS mode is on
Lan1 - Lan4 When a lan cable is connected the
corresponding light lits up.
