Back label
The back label describes the corresponding LED indications and port functionality.
LED Description
Power Lights up when powered ON. Blinks on
TEST/RESET
ADSL Lights up when an ADSL cable is
connected.
Internet Lights up when internet connection is UP.
WLAN Lights up in Blue when WLAN is enabled.
Blinks on traffic
OPS Blinks when OPS mode is on
LAN1~4 When a LAN cable is connected the
corresponding light lights up.
